DISCOVERY -DS 320 BRIQUETTER VERSION

DISCOVERY - DS 320 BRIQUETTER VERSION Air Flow rate 8000 m3/h - Filtering Surface Area 144 m2 - Fan Power 11 kw - Dimensions 3500x1100xH3310 mm
€14605.50 incl tax
decrease increase

Reliable, silent, and easy to install and to use. The DS compact range has been designed with the aim of optimizing the extraction efficiency reducing at minimum the unit sizes. F SERIES is suitable for the extraction of chips and dust of various natures, optimal for the filtration of fine-average granulometry particles. The filters work in negative pressure with a very high extraction efficiency (suitable for CN special machines). They can be installed inside the workshop (please check the local rules) or even outside. The unit is made up of galvanized painted panels and it is equipped with:

- Air settling chamber at the inlet, to protect the filtersfrom the impact with the transported materials
- Bag filters (500 gr/m) or cartridges (270 gr/m²), depending on the model, in high density polyester;

- Cleaning of the sleeves by means of jets of compressed air against the current, issued during the operation of the suction;
- High efficiency centrifugal fan with backward curved blades, installed in clean air and soundproofed;
- Emptying of waste in metal containers with viewing window to check the filling level.

For shipping costs, contact us at +39 0825 581 560 or by email info@ siaimpiantifaidate.com.

Reliable, silent, and easy to install and to use. The DS compact range has been designed with the aim of optimizing the extraction efficiency reducing at minimum the unit sizes. F SERIES is suitable for the extraction of chips and dust of various natures, optimal for the filtration of fine-average granulometry particles. The filters work in negative pressure with a very high extraction efficiency (suitable for CN special machines). They can be installed inside the workshop (please check the local rules) or even outside. The unit is made up of galvanized painted panels and it is equipped with:

- Air settling chamber at the inlet, to protect the filtersfrom the impact with the transported materials
- Bag filters (500 gr/m) or cartridges (270 gr/m²), depending on the model, in high density polyester;

- Cleaning of the sleeves by means of jets of compressed air against the current, issued during the operation of the suction;
- High efficiency centrifugal fan with backward curved blades, installed in clean air and soundproofed;
- Emptying of waste in metal containers with viewing window to check the filling level.
